| MODEL |
|
MS-IPD430P-PE-CV-AI |
| IMAGE SENSOR |
|
SONY EXMOR SENSOR |
| IMAGE RESOLUTION |
|
4 MP |
| EFFECTIVE PIXELS |
|
1920(H)*1080(V) |
| TV SYSTEM |
|
PAL/NTSC |
| ELECTRONIC SHUTTER TIME |
|
AUTO : PAL 1/1-1/10000SEC; NTSC 1/1-1/10000SEC |
| SYNC SYSTEM |
|
EXTERNAL |
| USABLE E ILLUMINATION |
|
0.001LUX |
| S/N RATIO |
|
≥52DB |
| SCANNING SYSYEM |
|
PROGRESSIVE SCAN |
| VIDEO OUTPUT MODE |
|
NETWORK |
| FOCUS LENGHT |
|
BOARD LENS 3.6MM |
| FOCUS CONTROL |
|
FIXED |
| LENS TYPE |
|
HD IR CORRECTED LENS |
| PIXELS |
|
4MP |
| INFRARED LED |
|
￠5X 18 PCS |
| INFRARED DISTANCE |
|
UP TO 25 METER |
| IR STATUS |
|
UNDER 10 LUX BY CDS |
| IR POWER ON |
|
CDS AUTO CONTROL |
| ONVIF |
|
SUPPORTS ONVIF 2.4 |
| ETHERNET |
|
RJ-45 (10/100BASE -T) |
| PROTOCOL |
|
IPV4, HTTP,TCP/IP, FTP, NTP, RTSP, UDP, SMTP, DNS, DDNS |
| P2P |
|
YES, SUPPORTS QR CODE |
| POE |
|
SUPPORTS IEEE 802.3 AF |
| ALARM I/0 |
|
NA |
| MAIN STREAM |
|
1080P@25FPS |
| SUB STREAM |
|
720*480@20FPS, 352*288@30FPS |
| IE BROWSER |
|
IE8-11, GOOGLE CROME, FIREFOX |
| SMART PHONE |
|
iPHONE, iPAD, ANROID |
| DAY/NIGHT |
|
COLOR IMAGE IN NIGHT / B&W (IR CUT) |
| COMPRESSION |
|
H.265/H.264/JPEG , SUPPORTS RECORD AVI FORMAT |
| IMAGE CONFIGURATION |
|
SATURATION/BRIGHTNESS/CONTRAST/SHARPNESS, MIRROR , 3D NR, WHITE BALANCE, BLC, FLK (FLICKER CONTROL) |
| MOTION DETECTION |
|
SUPPORTS |
| PRIVACY MASKING |
|
3 RECTANGULAR ZONE |
| WDR |
|
YES |
| RECORDING MODE |
|
NVR/NAS/CMS/WEB |
| LANGUAGE |
|
ENGLISG, BULGARIAN, POLISH, FARSI, GERMAN, RUSSIAN, FRENCH, KOREAN, PORTUGUESE, JAPANESE, TURKISH, SPANISH, HEBREW, ITALIAN |
| HOUSING |
|
PLASTIC BODY, IP 65 |
| OPERATION TEMPERATURE |
|
-20 ℃ ~+60℃ RH95%Max |
| STORAGE TEMPERATURE |
|
-20 ℃ ~+60℃ RH95%Max |
| POWER SOURCE |
|
DC12V±10%,1000mA |
| WEIGHT |
|
150G |
